Our stainless steel emergency exit door, featuring an integrated anti-panic function and an electric door guard with an audible warning signal, is the ideal solution for safety and reliability in emergency and evacuation routes. Designed to meet the highest standards, it combines functional safety with modern design and flexibility in use.
The escape door with a metal panel offers the following impressive features:
- Emergency Exit for Designated Evacuation Routes
- Made of durable round stainless steel tubing (Ø 42×2 mm, grade 1.4301)
- Available in defined standard sizes for width and height
- Flexible installation with tubular supports for floor or wall mounting
- Available in 3 versions
- Standard version: Anti-panic function with door guard in accordance with DIN EN 179
- Economical option: with anti-panic function only, without a door guard (see options)
- Optional with anti-panic feature and splash-proof door guard (see options)
- Upon request, the gate can be equipped with handles on both sides
- The door guard has the following version in accordance with DIN EN 179
Our gate, made of durable round stainless steel tubing (Ø 42×2 mm, grade 1.4301), combines stability with an attractive design. Three versions are available: with a Knee rail, with a filler panel, or with vertical struts. Flexible mounting options allow for attachment to floor or wall posts. The 1000 mm width is suitable for up to 20 people, while the 1200 mm width is designed for up to 200 people. Upon request, custom widths can also be manufactured to meet individual requirements.
For use in escape and rescue routes, the escape door is equipped as standard with an anti-panic function and a door monitorin accordance with DIN EN 179. The anti-panic function allows the door to be opened immediately by simply pressing the handle, even when locked. The electric door monitor emits an audible warning signal if the door is opened without authorization. In addition, two further variants are available: a simplified version with an anti-panic function but without a door monitor, and a splash-proof variant with a door monitor for damp environments.
For user-friendly operation, the door is equipped as standard with a lever handle on one side and a knob on the other, while the door guard ensures additional security in accordance with DIN EN 179. The EltVTR regulations do not need to be taken into account in this case. Upon request, the gate can be fitted with handles on both sides.
Important note: To ensure maximum safety and compliance with all relevant regulations, the planned door width must be determined in consultation with the building owner and the fire safety department, taking ASR A2.3 into account. This ensures compliance with all relevant safety regulations.
- Housing: 1.4301 stainless steel
- Dimensions (floor mounting):
- 1280 mm x 960 mm (width x height)
- Clear passage width: 1000 mm
- Item Number: EKH-00121
- Dimensions (wall mounting):
- 1280 mm x 960 mm (width x height)
- Clear passage width: 1000 mm
- Item Number: EKH-00131
- Dimensions (floor mounting):
- 1280 mm x 1300 mm (width x height)
- Clear passage width: 1000 mm
- Item Number: EKH-00122
- Dimensions (wall mounting):
- 1280 mm x 1300 mm (width x height)
- Clear passage width: 1000 mm
- Item Number: EKH-00132
- Dimensions (floor mounting):
- 1480 mm x 960 mm (width x height)
- Clear passage width: 1200 mm
- Item Number: EKH-00123
- Dimensions (wall mounting):
- 1480 mm x 960 mm (width x height)
- Clear passage width: 1200 mm
- Item Number: EKH-00133
- Dimensions (floor mounting):
- 1480 mm x 1300 mm (width x height)
- Clear passage width: 1200 mm
- Item Number: EKH-00124
- Dimensions (wall mounting):
- 1480 mm x 1300 mm (width x height)
- Clear passage width: 1200 mm
- Item Number: EKH-00134
- Flange plate: 120 mm x 120 mm x 8 mm
